GAIN CONTROL menu

Item
AUTO
BLACK LEVEL
CONTRAST
RESET
Notes about auto adjustment:
- If you are not using the Adjustment Pattern, it is necessary to have black area and white area of at
least 5 mm x 5 mm on the screen. Adjustment may not be possible without those areas.
- If the signal coming from the computer is Composite Sync or Sync on Green, automatic adjustment
may not be possible. Please perform manual adjustment instead.
- If "OUT OF ADJUST" is displayed, perform manual adjustment.

COLOUR CONTROL menu

Item
COLOUR MODE
WHITE BALANCE
RESET
Note:
- "WHITE BALANCE" will be automatically set to "STD" when "COLOUR MODE" is set to "sRGB" or
"VIVID".
All manuals and user guides at all-guides.com
Adjusting the display
Description
Automatically adjusts "BLACK LEVEL" and "CONTRAST" based on the
brightest and darkest colours of the image displayed.
Adjusts screen brightness while you watch the colour pattern.
Colour pattern
Adjusts contrast so that all gradations appear while you watch the colour
pattern.
Resets adjustment values for this menu to their original factory settings.
Description
Selects the colour tone.
- STD ........... Displays images using the original colour tone of the LCD
monitor.
- sRGB ........ sRGB is an international standard for colour representation
defined by the IEC (International Electrotechnical
Commission). Colours are converted by taking into account
the liquid crystal's characteristics and thereby represent
colour tone close to the original image.
- VIVID ........ Displays images in vivid primary colours.
Adjusts the colour temperature.
Set "WHITE BALANCE" to "STD" if you want to display all gradations.
- COOL2 ..... Colour tone bluer than standard.
- COOL1 ..... Colour tone slightly bluer than standard.
- STD ........... Standard setting for colour tone.
- WARM1 .... Colour tone slightly redder than standard.
- WARM2 .... Colour tone redder than standard.
- USER ........ Allows you to individually adjust red, green, and blue
contrast.
Resets adjustment values for this menu to their original factory settings.
