4.3 Controller parameters

Address Data type/
bit number
0x3000 FLOAT
0x3002 FLOAT
0x3004 FLOAT
0x3006 FLOAT
0x300C FLOAT
0x300E FLOAT
0x3010 FLOAT
0x3012 FLOAT
0x3014 FLOAT
0x3016 INT
0x3017 INT
0x3018 INT
0x3019 INT

4.4 Configuration

Address Data type/
bit number
0x0053 FLOAT
0x0055 FLOAT
0x0057 FLOAT
0x0059 FLOAT
0x005D FLOAT
0x005F FLOAT
0x0063 LONG
0x0065 LONG
0x0067 TEXT4
0x0069 LONG
All manuals and user guides at all-guides.com
Access Signal designation
R/W Controller parameter XP1
R/W Controller parameter XP2
R/W Controller parameter TV
R/W Controller parameter TN
R/W Controller parameter CY1
R/W Controller parameter CY2
R/W Controller parameter XSH
R/W Controller parameter XD1
R/W Controller parameter XD2
R/W Controller parameter TT
R/W Controller parameter Y0
R/W Controller parameter Y1
R/W Controller parameter Y2
Access Signal designation
R/W Ramp function, ramp rate
R/W Filter time constant (digital filter)
R/W Limit comparator 1 Alarm value AL
R/W Limit comparator 1 Hysteresis
R/W Limit comparator 2 Alarm value AL
R/W Limit comparator 2 Hysteresis
R/W Timer value
R/W Service limit value
R/W Alarm text
R/W Service counter
4 Modbus addresses
