2 Protocol description
2.9

Error processing

Error codes

The following error codes exist:
Response in
Slave
the
address
event of an
1 byte
error
0x80 is used to set the function code to its OR status, i.e. the MSB (most
significant bit) is set to 1.
Example
Data request:
01
Response (with error code 2):
01

Special cases

The slave not responding can have the following causes:
- the baud rate and/or data format of Master and Slave are not compatible
- the device address used does not coincide with that of the slave address
- the checksum (CRC16) is not correct
- the instruction from the Master is incomplete or over-defined
- The number of words to be read is zero.
In these cases the data request should be transmitted again once the timeout
time (2 s) has elapsed.
18
All manuals and user guides at all-guides.com
1 invalid function
2 invalid parameter address or too many words
are to be read or written
8 write access to parameter denied
Function
XX OR 80h
1 byte
03 40 00 00
83 02 CRC16
Error code Checksum
CRC16
1 byte 2 bytes
04 CRC16
