C-Control I/O Terminal
How to Connect the I/O Terminal
The I/O TERMINAL is ready for operation as soon as is has been connected properly to the
C-Control STATION.
Please bear in mind that connecting must only be performed when the STATION is off-line.
• Apply operating voltage to the I/O TERMINAL, connecting terminal 1 and 2 to a 12V power
supply. You may use STATION terminals 9 (12V OUT) and 8 (GND).
Warning:
Please pay attention to correct polarity!
Polarity reversal can destroy the IOT.
12V
GND
• Connect the interface lines of the IOT to the corresponding STATION ports.
CLOCK
DATA
STROBE
AD
LAMP
The LAMP port is only relevant for the version with LCD backlight.
• Connect extention ports P1 to P8 to your application.
EXT. PORT P1
EXT. PORT P2
EXT. PORT P3
EXT. PORT P4
EXT. PORT P5
EXT. PORT P6
EXT. PORT P7
EXT. PORT P8
16
IOT
TERMINAL 1
TERMINAL 2
IOT
TERMINAL 15
TERMINAL 16
TERMINAL 17
TERMINAL 18
TERMINAL 19
TERMINAL 21
TERMINAL 22
TERMINAL 23
TERMINAL 24
TERMINAL 10
TERMINAL 11
TERMINAL 12
TERMINAL 13
STATION
TERMINAL 9
TERMINAL 8
STATION
P6, TERMINAL 33
P5, TERMINAL 32
P4, TERMINAL 31
AD4, TERMINAL 26
P3, TERMINAL 30
