Handling

Input/ output operations at the STATION are restricted to a few LED indicators and keys. Quite a
number of applications, however, require operations such as control of measuring values or
adaptation of operating parameters.
The I/O terminal is delivered with a numeric keyboard disposing of a CLEAR and ENTER key. The
available LEDs, additional functions keys, 8 additional ports and a small 2x8 LCD live up to the most
sophisticated application tasks.
The IOT is directly connectable to the STATION (it does not require a 2W-SM modem). The supplied
comprising demonstration programs ensure fast access to programming of routines relevant to the
IOT.
IO_TERMINAL_1:
IO_TERMINAL_2:
IO_TERMINAL_3:
IO_TERMINAL_4:
IO_TERMINAL_5_IO_WRITE:
IO_TERMINAL_6a_IO_WRITE: access to I/O extension unit, LED control
IO_TERMINAL_6b_IO_WRITE: access to I/O extension unit, LED control
IO_TERMINAL_6c_IO_WRITE: access to I/O extension unit, port control
The IOT version with LCD backlight is additionally equipped with a short demonstration program for
adjustment of the display luminosity: IO_TERMINAL_DIMMER_UTILITY
It might be necessary to change the keyboard code because of technical modifications. The
delivered utility IO_TERMINAL_KEY_UTILITY enables the user to read out analog values assigned to
certain keys and to adjust the decoder table accordingly.
Please visit us on our Homepage for updates and information on C-Control products:
www.c-control.de
line-by-line writing, time indication
indication of a 16-bit digit
binary indication of port states
indication of temperature measured by the STATION
access to I/O extension unit, LED control
