15. Technical Data

Supply voltage:
Connected load:
Temperature switching points:
Temperature control area:
Frost protection function:
Scale protection function:
Switching contact:
Dimensions:
Weight:
Sensor cable length:
Protective degree for sensor/cable: IP68
Attention!
The protection class IP68 applies only for the sensor or
cable but not for the housing of the universal thermo-
stat as such.
It must not become damp or wet. There is danger to life
from a fatal electric shock!
230 V/AC, 50 Hz
3680 W (230 V/AC, 16 A)
Max. 7 per day
-20 °C to +70 °C
(basic setting +5.0 to +45.0 °C,
adjustable via function G7
"TEMP LIMITS")
Yes (can be activated/deacti-
vated)
Yes (can be activated/deacti-
vated)
Relay, single-pole
75 x 130 x 37.5 mm (W x H x D,
no plug)
340 g (incl. cable)
Approx. 2 m
