When the thermostat is in automatic mode (
16:00, the thermostat sets the room temperature (the default setting is 15 ºC) according
to the current period (by default, the afternoon period is 12:30-17:30). If you finish work 1
hour earlier on this day (16:30 is 1 hour earlier than 17:30), you can press the
button to temporarily adjust the temperature to the desired level (e.g. 20 ºC). This room
temperature will be maintained until the next time period.
The
and
symbols will flash when the temperature has been set manually.
7.5 Default time periods
Time period
Symbol
Working day
Weekend
7.6 Manual and automatic mode
The thermometer can be switched between manual and automatic mode.
To switch between manual and automatic mode, short press the
Manual mode
7.7 Advanced settings
Hold down the
button to access the advanced settings, and then press the
select an option.
To set a value, press
or
, then press
The setting will be automatically saved after 5 seconds.
No. Display
Setting
code
1
A1
"Window open" mode
The number of degrees
by which the tempe-
rature must fall over a
preset time period in
order to detect an open
window.
2
A2
Temperature
control sensors
Return difference
3
A3
Highest temperature
setting
4
A4
Lowest temperature
setting
5
A5
Temperature calibration
6
A6
Antifreeze function
7
A7
Memory for on/off state
after power cut
8
A8
Operating mode
9
A9
Programming mode
10
AA
Factory default settings
), for example when the current time is
Time
Temperature
06:00
20°C
08:00
15°C
11:30
15 °C
12:30
15 °C
17:30
20°C
22:00
15 °C
08:00
20°C
23:00
15 °C
button.
Automatic mode
to move to the next option.
Function
Default setting
"--" means that
Press the
button to
Window mode is
enable, Display:
disabled.
5 °C, Temperature
Duration:15 minutes
trigger range: 5-25 °C,
time setting range: 5-60
minutes
1 to 9 °C
2°C
20 to 70 °C
35°C
1 to 10 °C
5 °C
+/- 5 °C (displayed room
0.5°C
temperature)
00: Antifreeze function
00: Antifreeze
disabled
function disabled
01: Antifreeze function
enabled
00: Thermostat off
01
01: Thermostat on/
off with memory (when
power supply is switched
on)
00: Cooling mode
01: Heating mode
01: Heating mode
00: Automatic mode
00:
enabled
Automatic mode
enabled
01: Automatic mode
disabled
00: Factory default
setting
8 Cleaning and care
This product does not require any maintenance. Never attempt to dismantle it. Disconnect
the product from the mains supply before cleaning. Dust can easily be removed using a
or
clean, soft brush and a vacuum cleaner. Do not use abrasive cleaning agents, cleaning
alcohol or other chemical solutions, as these could damage the casing, impair operation or
cause discolouration. To prevent scratch marks, do not press too strongly on the surface
when cleaning.
Disconnect the product from the mains and the connected device before cleaning.
Do not immerse the product in water.
9 Disposal
All electrical and electronic equipment placed on the European market must be
labelled with this symbol. This symbol indicates that this device should be disposed
of separately from unsorted municipal waste at the end of its service life.
All owners of waste equipment are obliged to dispose of waste equipment separa-
tely from unsorted municipal waste. Before handing the old device to a collection
point, end users are required to separate old batteries which are not enclosed by
the old device, as well as lamps which can be removed from the old device without
any damage.
Distributors of electrical and electronic equipment are legally required to accept waste equip-
ment free of charge. Conrad provides the following return options free of charge (more details
on our website):
At our Conrad stores
At the collection points established by Conrad
At the collection points of public waste disposal agencies or at the collection systems set up
by manufacturers and distributors in accordance with the German Electrical and Electronic
Equipment Act.
The end user is responsible for deleting personal data on the old device before disposal.
button to
Please note that in countries outside Germany, other obligations may apply to the return and
recycling of old devices.
10 Technical data
10.1 Power supply
Rated voltage ........................................... 230 V/AC, 50 Hz
10.2 Connected load/current
Resistive load ........................................... Max. 3680 W / 16 A
Inductive load ........................................... 2 A 460 W
Power consumption when idle < 1.5 W
10.3 Thermostat
Protection rating ....................................... IP20
Protection class ........................................ 1
Number of sockets .................................... 1
Relay ........................................................ Normally open
Operating state ........................................ S1
Temperature display range ....................... -10 to +70 °C
Display accuracy ...................................... +/-0.5 °C
Length of temperature sensor cable ......... 2.5 m
Sensor ...................................................... NTC (10k) 1 %
10.4 Miscellaneous
Dimensions (W x H x D) ........................... 66 x 135 x 77 mm
Weight ...................................................... 220 g
10.5 Ambient conditions
Operating conditions ................................. 0 to +50 °C, max. 80% RH (non-condensing)
Storage conditions .................................... -10 to +60 °C, max. 80% RH (non-condensing)
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com).
All rights including translation reserved. Reproduction by any method, e.g. photocopy, microfilming, or the capture in
electronic data processing systems require the prior written approval by the editor. Reprinting, also in part, is prohibited.
This publication represent the technical status at the time of printing.
Copyright 2023 by Conrad Electronic SE.
*2686283_V2_0423_02_m_VTP_EN
