1. Preface

LEAKSHIELD is a worldwide unique leakage protection system for liquid cooling
systems developed by Aqua Computer. It actively generates an optimally compu-
ted negative pressure in the cooling system which actively prevents the escape of
coolant in the event of a leak.
If a leak occurs, only air is sucked into the cooling system.
For this purpose, an integrated vacuum pump is activated in a fraction of a second
in the event of a leak and continues to maintain the required vacuum.
In addition, LEAKSHIELD uses a highly accurate sensor to detect and indicate even
minimal leaks. This allows countermeasures to be taken at a very early stage.
The system is also able to determine the fill level in the reservoir.
LEAKSHIELD was developed for the ULTITUBE reservoir series, but can also be
used with other reservoirs, e.g. from the aqualis, aquatube or aquainlet series, via
an adapter set (LEAKSHIELD UNIVERSAL). For further information, please refer to
the corresponding instructions for the adapter set.
LEAKSHIELD has an OLED display and a button control which allow the most im -
portant functions to be controlled directly on the device.

2. Safety precautions

The following safety precautions have to be observed at all times:
Read this manual thoroughly and entirely!
●
Save your data onto suitable media before working on your hardware!
●
This product is not designed for use in life support appliances, devices, or
●
systems where malfunction of this product can reasonably be expected to re-
sult in personal injury. Aqua Computer GmbH & Co. KG customers using or
selling this product for use in such application do so at their own risk and
agree to fully indemnify Aqua Computer GmbH & Co. KG for any damages
resulting from such application!
Never touch the membrane on the bottom side of LEAKSHIELD. Damage to
●
the membrane can cause moisture to enter LEAKSHIELD and subsequently
