14.3. System alarm

The system alarm is triggered in case of errors at LEAKSHIELD or the power supply.
Only the action in case of an alarm can be selected.
System alarms are always evaluated and visualized acoustically and optically.

15. The Status page

Click on the "Status" device page below the "LEAKSHIELD" entry.
On the Status page, all current operating data of LEAKSHIELD are visualized. For
this purpose, the status, the current negative pressure, the volume change in ml/h
and the pressure change in mbar per minute are displayed as values in the upper
area.
By clicking on one of the radio buttons, the corresponding value can be displayed
in a diagram below in the change over time.
The size of the diagram can be changed by using the dividing line below the dia -
gram.
In the middle of the page a symbolic illustration of LEAKSHIELD is shown. This
shows the components of the system, such as the vacuum pump, valves, etc., re-
presented by symbols.
Currently active components are displayed in green. All important measured valu-
es are shown in the schematic.
In the lower part of the page, the current events are displayed in a list together
with the time and further details. In case of malfunctions, this list can be exported
and sent to Aqua Computer for further analysis.

16. Profiles

Select "Profiles" from the device list below the "LEAKSHIELD" entry.
The profile management can be used to to save four configurations as
profiles and activate them manually or automatically. Profile manage-
ment is a software feature of the aquasuite and requires a USB connection to the
LEAKSHIELD.

16.1. Manual profile selection

Select the profile to be activated by clicking the corresponding button.
