Display Settings; Rgbpx Configuration - Aqua Computer LEAKSHIELD Betriebs- Und Montageanleitung

LEAKSHIELD
If you want to display data from the hardware monitoring, for example, these must
be provided via a software sensor. Then the corresponding software sensor can
serve as data source for a template. In some cases, icons can also be selected for
the values or your own icons can be loaded.
In the template "Logo" you can display your own logo.
For each page you can select whether it should be displayed in standby of the PC
and whether it should be displayed in normal operation.
This allows a different selection of pages to be displayed for standby and operati-
on.

12.2. Display settings

The brightness of the display as well as an automatic change of the display pages
can be configured.
The brightness can also be set for inactivity (no user interaction) and the display
can be switched off completely.
In addition, settings can be made here as to whether and after what time the dis-
play pages should change automatically.
The other options allow the display to be rotated by 180° and the display to be in-
verted.
Automatic inversion is activated at the factory. This significantly reduces the burn-in
of permanently activated pixels, which is typical for OLEDs.
As with all OLED displays, the brightness of active pixels decreases over time. For
homogeneous wear of all pixels, the display can be operated inverted half the
time. To compensate for existing wear, the inverted mode can also be activated
permanently.
The last option available here is the automatic shutdown of the display in standby.
This option significantly increases the life span of the display!

13. RGBpx configuration

Select "RGBpx" from the device list below the "LEAKSHIELD" entry. The
integrated RGBpx lighting (6 LEDs) can be configured.
