LEAKSHIELD
10.3. The "Measure fill level" action
If you activate the fill level measurement by clicking on the symbol "Measure fill le-
vel", a bar graph appears in the lower area which shows you the progress of the
measurement.
To do this, LEAKSHIELD first releases the negative pressure and then generates a
low negative pressure of approx. 100 mbar. The result of the measurement is then
displayed.
Note: There is no sufficient leakage protection during the level measurement. If
you have reason to believe that your system is not completely tight, you should not
activate the level measurement!
10.4. The "Deaerate system" action
After activating the action "Deaerate system", two progress bars appear. The first
shows the progress of the current cycle, the second the overall progress.
During this action, negative pressure is cyclically built up and released again. This
removes trapped air in the system step by step through expansion and compressi -
on.
10.5. The "Refill system" action
If the action "Refill system" is selected, LEAKSHIELD generates a negative pressure
between 250 and 300 mbar. Coolant can be sucked into the system by this.
Pressing the "Pause" button pauses the pumping action, but the vacuum is not
released. This prevents coolant from flowing back into the container.
If the process is terminated by pressing the "Exit" button, LEAKSHIELD switches to
the previously selected mode.
11. Sensor configuration
Select "Sensors" from the device list below the "LEAKSHIELD" entry. In the
upper area of the window, the 18 usable sensors are displayed with the
actual measured value. In the lower area of the window, the configurati-
on of the selected sensor can be made.
There are local sensors, sensors with extended configuration and software sensors
in this selection.
- 18 -
