13.1. Create and configure additional LED controllers

New LED controllers can be added by clicking the plus symbol. Alterna-
tively, use the right mouse button and select "New" from the context
menu. Select the desired effect from the superimposed list of available ef-
fects. The controller name can be altered from its default as well. Confirm you se-
lection by clicking the check symbol in the lower right corner.
The configuration of the newly added LED controller can be modified in the lower
area of the window. Most effects offer extensive customization options such as co-
lor selection or speed adjustment. Additionally, many effects can be configured to
modify effect parameters depending on current sensor data.
In total, up to eight LED controllers (two for integrated lighting, six for external
components) can be configured.

13.2. Modify existing LED controllers

Existing LED controllers can be selected by clicking the corresponding co-
lor bars, the configuration of the selected controller can then be modified
in the lower area of the window.
By clicking the gear symbol, the effect to be displayed can be changed and the
controller name can be altered. Confirm you selection by clicking the check sym-
bol in the lower right corner.

13.3. Modify LED assignments

Existing LED controllers can be moved by using "drag&drop"on the corre-
sponding color bars. The horizontal position of the color bar defines the
position of the effect on the connected LEDs. The vertical position deter-
mines the priority of the LED controllers, if multiple controllers are assigned to a
range of LEDs. Controllers positioned further up in the list have higher priority than
controllers further below.
The length of the bar (corresponding to the number of LEDs assigned) can be
changed by moving the right/left edge of the color bar.

13.4. Duplicate LED controllers

Select the LED controller(s) to be duplicated and click the duplicate sym-
bol to create new LED controllers using identical configurations. Alterna-
tively, use the right mouse button and select "Duplicate" from the context
menu.
In total, up to eight LED controllers (two for integrated lighting, six for external
components) can be configured.
