NOTE: Changes are saved automatically to the current Specialty.
NOTE: All other settings (Device, Media, Printer, etc.) are not specific to a Specialty. Changes
to those settings stay in effect regardless of which Specialty is selected.

5.4.2 Advanced Settings: Device Settings

Icon/Setting Description
Increase
Decrease
When Camera Head is selected, the light source illuminates only turn on
Light Source when a camera head is connected to the Camera Control System . The light
Guard source will automatically turn off when the camera head is disconnected from
the Camera Control System .
The light Source level sets the light intensity of the light source . This level
Light Source
should always be at its maximum during normal surgical use .

Figure 16. Device Settings

Table 14. Device Settings
