Chapter 3
Operator Controls, Displays and Alerts
This chapter describes operator controls, displays, and alerts on the System . Operating
instructions for system accessories are described in separate instructions for use (refer to "1 .6,
Compatible Devices") .
Figure 1 shows the front of the Camera Control System .
3.1

Front Panel Controls and Displays

No. Description
1
Power Button
2
Olympus Light Cable Female Port
3 LCD Touch Screen
4 Two (2) USB-A 3 .0 Female Ports
5 Camera Head LED Indicator
6
Camera Head Connector

Figure 1. Camera Control System Front Panel

Table 1. Front Panel Controls

12
