Chapter 5
Operating Instructions
5.1

Startup and General Operation

When the Camera Control System is on, an initial startup screen appears, followed by the
Patient Information Screen after several seconds (Figure 6) . During normal use, the Camera
Control System does not require attention; it is designed to function with, or without user input
until it is turned off .
Icon Description
Go to Home Screen
Start Case
Selected Item

Figure 6. Patient Information Screen

Table 6. Patient Information Screen Icons

22
