Menü "Tanks" - Tankdetails
34
Beispiel für eine Tanktabellendatei
<NXA820 CRC="12345">
<TCT TCT_Date="7/3/2005" TCT_CalDate="1/1/2002" Sub_TCT="Y" WATER_TCT="Y">
<Level_Type>Innage</Level_Type>
<Units>
<Level>m</Level>
<Volume>m3</Volume>
<P_Density_FRA>kg/m3</P_Density_FRA>
</Units>
<FRA_TCT>
<P_Density_FRA>800</P_Density_FRA>
<V_FRC>1.01234</V_FRC>
</FRA_TCT>
<Heel_Volume>100</Heel_Volume>
<Total_Tank_Volume>1100</Total_Tank_Volume>
<Max_Tank_Capacity>900</Max_Tank_Capacity>
<Min_Pump_Volume>1000</Min_Pump_Volume>
<Volume_Method>RAW</Volume_Method>
<Min_Sub_TCT_Level>0.5</Min_Sub_TCT_Level>
<P_TCT CNT="9">
<P_Strap>
<P_Level>0</P_Level>
<P_Vol>50</P_Vol>
</P_Strap>
<P_Strap>
<P_Level>1.25</P_Level>
<P_Vol>168.75</P_Vol>
</P_Strap>
<P_Strap>
<P_Level>10</P_Level>
<P_Vol>1000</P_Vol>
</P_Strap>
</P_TCT>
<P_S_TCT CNT="5">
<P_S_Strap>
<P_S_Level>0</P_S_Level>
<P_S_Vol>0</P_S_Vol>
</P_S_Strap>
<P_S_Strap>
<P_S_Level>1</P_S_Level>
<P_S_Vol>77.497</P_S_Vol>
</P_S_Strap>
</P_S_TCT>
<Water CNT="5">
<W_Strap>
<W_Level>-1</W_Level>
<W_Vol>0</W_Vol>
</W_Strap>
<W_Strap>
<W_Level>1</W_Level>
<W_Vol>100</W_Vol>
</W_Strap>
</Water>
</TCT>
</NXA820G>
Tankvision NXA820, NXA821, NXA822
Main Table
Sub Table
Water Table
