Sartorius Sartocon Slice Self Contained Gebrauchsanleitung Seite 14

Components Filter Device
1
Fig. 7: Filter Loop Assembly
Pos . Description
1 Opta Male ½" HB
®
2 Colour-coded cable tie
3 Single Use pump head
4 Pinch clamp
5 Pressure domes
6 TMP Control valve
7 Opta (connect according to colour coding)
®
8 Opta Male ½" HB
®
9 Opta
Female ½" HB
®
10 Coupling Female ¼"
Filter Loop Assemblies for Flexact
Order No . Screen
4XC48 E
4XC31 ECO
4XC27 ECO
4XC40 ECO
4XC41 ECO
4XC32 ECO
4XC28 ECO
4XC34 ECO
4XC37 ECO
4XC29 ECO
4XC33 ECO
4XC35 ECO
4XC38 ECO
14 Instructions for Use Sartocon
6
2
5
2
3
®
Membrane |
Material
Hydrosart
®
Hydrosart
®
Hydrosart
®
PESU
PESU
Hydrosart
®
Hydrosart
®
PESU
PESU
Hydrosart
®
Hydrosart
®
PESU
PESU
Slice Self Contained | Sartocube
®
7
4
10 4
Nominal Molecular
Weight Cut-off
5 kD
10 kD
10 kD
10 kD
10 kD
30 kD
30 kD
30 kD
30 kD
100 kD
100 kD
100 kD
100 kD
Self Contained
®
Effective Filtration Area
[m²]
1.2 m²
1.4 m²
3.5 m²
1.4 m²
3.5 m²
1.4 m²
3.5 m²
1.4 m²
3.5 m²
1.4 m²
3.5 m²
1.4 m²
3.5 m²
