ASSEMBLY AND PROGRAMMING INSTRUCTIONS
EquaScan pMIU
Pulse Meter radio module
SCOPE OF DELIVERY
• Pulse Meter RF communication module
• Assembly instructions
• 5 "Scotch Lock" type connectors for signal cable diameter 1,52
• 1 user plastic seal
• 1 screw 3,5x20 for wire cover
GENERAL INFORMATION
The EquaScan pMIU
serves to integrate pulse emitting meters into the Itron EquaScan radio system for mobile and fixed
RF
network data collection.
The module can be assembled, installed and integrated into the system of existing EquaScan radio meters in a few simple
steps. The EquaScan pMIU
software.
IMPORTANT NOTIC FOR LITHIUM-BATTERIES
The device contains non-replaceable lithium metal batteries. Do not charge batteries, do not expose to temperatures
exceeding 100°C or mechanical stress. Transport regulations for lithium batteries should be considered. The certificates
required for transport can be requested from the manufacturer. Do not expose to low air pressure and high altitude.
CORRECT DISPOSAL / INFORMATION ON APPROPRIATE PRODUCT DISPOSAL
The crossed-out wheelie symbol on the equipment or on its packaging indicates that the end-of-life product must be col-
lected separately from household waste for proper treatment and recycling. Check with the local authority about the location
of appropriate ecological platforms and its subsequent correct recycling. In the case of the purchase of an equivalent device,
the distributor is required to collect the product to destroy. The product is not potentially harmful to human health and the
environment, but if it is abandoned in the environment, it has a negative impact on the ecosystem. Abandonment of the
equipment or the illegal disposal of the equipment in the environment is punishable by law.
The battery symbol on the module indicates the end year of the battery life.
For the European market.
Degree of protection against dust and water.
PRE-INSTALLATION PRECAUTIONS
Prior the installation of the EquaScan pMIU
Where electronic devices are to be utilized, caution should be exercised to ensure that the EquaScan pMIU
in close proximity to power supply cables or strong electromagnetic sources such as electric motors or pumps.
Maximum installation height is limited to 2 m. Do not install the EquaScan pMIU
heat, or exposed direct to the sunlight. Ensure that the module is properly secured.
Radio specifications
Protocol
Operating mode
Frequency Band
RF
can be programmed quickly via the computer using an Itron inductive head and the EquaScan
RF
, check if the meter is equipped with a pulse output.
RF
EN 13757-3/-4 wireless M-BUS
C2 Mode
Tx: 868,95 MHz / Rx: 869,525 MHz
on hot water piping, close to any source of
RF
is not installed
RF
