Instructions
PSH Compressors
PSH038-051-064-077
3
2
5
1. Discharge temperature sensor (supplied with AKA option, but
need to be connected)
2. Liquid Injection Valve
3. Liquid Injection Valve connection 1/4" ODF
4. Surface Sump Heater (SSH) (supplied with AKA option only)
5. Rigid mounting spacer (supplied with AKA option only)
Danfoss scroll compressors PSH038-051-064-077
electronic board OCS (Operating Control System) protecting against phase loss/reversal, motor
overheating, high current draw, and giving extra features such as liquid injection, discharge tem-
perature protection, envelope monitoring, data storage, bus communication and crankcase heater
control. PSH with option ABA are delivered only with a standard protection module. The liquid
injection and the crankcase heater control shall be ensured by an external controller MCX061V. The
respect of the application envelope must be ensured by the system controller.
70
65
2.2
60
55
50
45
40
35
2.1
30
25
20
15
10
5
0
-5
-10
-15
-20
-25
-40
-35
-30
-25
-20
Area1: Continuous running SH 5K to 20K
Area 2.1: 31 s maximum
The compressor must only be used for its
designed purpose(s) and within its scope of
application (refer to «operating limits»).
Consult Application guidelines and datasheet
available from cc.danfoss.com
1 – Introduction
These instructions pertain to the Danfoss PSH
scroll compressors used for heat pump and air-
conditioning systems. They provide necessary
information regarding safety and proper usage
of this product.
2 – Handling and storage
• Handle the compressor with care. Use the
compressor lifting lugs and use appropriate
and safe lifting equipment.
2 | AN15788643385602-000401 - 8510263P01AA
1
4
with AKA option
1
2.3
3
-15
-10
-5
0
5
10
15
20
T
(°C)
0
Area 2.2: 31 s maximum
Area 2.3: 3 min maximum
Under all circumstances,
the EN378 (or
applicable
regulation)
must be fulfilled.
• Avoid any shocks to the liquid Injection valve
during handling operations.
• Store and transport the compressor in an
upright position.
• Store the compressor between -35°C and 50°C.
• Don't expose the compressor and the packa-
ging to rain or corrosive atmosphere.
3 – Safety measures before assembly
Never use the compressor in a flammable
atmosphere.
PSH051A4AKA
Model no :
A
BE1106279537
B
Serial no :
0038
C
Refrigerant: R410A
PROTECTED BY DOMESTIC AND FOREIGN PATENTS
A: Model number
- Option AKA fitted with Operation
control system (OCS)
- Option ABA fitted with standard
protection module
B: Serial number
Installation and servicing of the compressor by qualified personnel only.
Follow these instructions and sound refrigeration engineering practice
relating to installation, commissioning, maintenance and service.
come equipped with an
25
30
35
40
45
50
Area 1+2.3+3: Start / Restart map
Discharge pressure warning
The compressor is delivered under ni-
trogen gas pressure (between 0.3 and
other
0.7 bar) and hence cannot be connec-
local
safety
ted as is; refer to the «assembly» section
requirements
for further details.
M A D E I N F R A N C E
380-415V 3~50Hz
UL electrical
460V 3~60Hz
ratings
LR R215A
MAX OPER. 51 A
M
Thermally protected system
P.E.D.
LP Side
HP Side
Marking
PS
31,20 bar
48 bar
TS Max
52 °C
68,3 °C
TS Min
-35 °C
-35 °C
Volume
28,5 L
2,5 L
Lubricant:P.O.E. 160SZ
C: Refrigerant
D: Supply voltage, Starting current & Maximum
operating current
E: Housing service pressure
F: Factory charged lubricant
CC
A1
LPS
A3
OCS/MPM
A2
KS
Legend:
Fuses ..........................................................................................F1
Compressor contactor .........................................................KM
Control relay ...........................................................................KA
Safety lock out relay .............................................................. KS
Optional short cycle timer (3 min) ............................... 180 s
High pressure safety switch.................................................HP
Control device .........................................................................TH
Fused disconnect ...................................................................Q1
Compressor motor ................................................................. M
Thermistor chain.......................................................................S
Safety pressure switch ........................................................ LPS
Control circuit ........................................................................CC
Operating Control System ............................................... OCS
The compressor must be
handled with caution in the
vertical position (maximum
offset from the vertical : 15°)
• The compressor ambient temperature may
not exceed 50°C during off-cycle.
• Mount the compressor on a horizontal flat
surface with less than 3° slope.
• Verify that the power supply corresponds to the
compressor motor characteristics (see nameplate).
• When installing PSH, use equipment specifi-
cally reserved for HFC refrigerants which was
never used for CFC or HCFC refrigerants.
• Use clean and dehydrated refrigeration-grade
copper tubes and silver alloy brazing material.
• Use clean and dehydrated system components.
© Danfoss | Climate Solutions (CC) | 2021.02
D
E
F
S
