Commend GE 150 Kurzanleitung

Intercom Server GE 150
Connection diagram
Expansion plug
IP
Music / Alarm
input
GE 150
MUSIC
RS232
IN1
IN2
Inputs for
floating
contacts
OUT1 OUT2
OUT1 OUT2
Floating outputs (relays)
Mounting, Dimensions
Measuring units in mm (inch), not scale!
306 (12.1)
*
Attention
Achtung: Darf nur durch geschultes Personal geöffnet werden
OBSERVE PRECAUTIONS FOR HANDLING Attention: May only be opened by qualified persons!
OF ELECTROSTATIC SENSITIVE DEVICES!
Attention: Seul ie personnel qualife est autorise a l ouvrir!
* Protection against contact acc. to IEC/EN 60950-1: For installation in the
operator access area, the housing cover has to be screwed onto the housing.
Slot number
1 2 3 4 5
Status LED
M3
+24V –
A A
B B
C C
D D
290 (11.4)
GE 150
Attentie: Mag alleen geopend worden door gekwalificeerd personeel!
Attenzione: Darf nur durch geschultes Personal geöffnet werden
Atencion: Darf nur durch geschultes Personal geöffnet werden
Cable run
Power
ON
OFF
Warning:
This is a Class A product. In a domestic environment this product may cause radio inter-
ference in which case the user may be required to take adequate measures.
To download the latest software and documentation, enter
the PIN code to the right at: pin.commend.com
Disposal and recycling
Equipment with this symbol shall not be disposed of together with household or
commercial waste. The directive 2012/19/EU on waste electrical and electronical
equipment (WEEE) is applicable in the European Union member states.
*
Attention
Observe the precautions for handling of electrostatic sensitive devices!
The device may only be installed by authorised engineers!
Manufacturer's reference
Type: D-BZ-GE150, Version: 1.2/0315
GE 150
A
B
C
D
Cable bearer Cable clamp NAK 100
4
/
Analogue
RJ11/RJ45-Socket
This equipment fulfils the requirements of the directive
2014/30/EU (EMC). Therefore, this equipment is CE-labelled.
Keep this description in safe custody.
www.commend.com
M3
Grounding point
for wrist strap
grounding
+24V –
min.
120 mm
(4.7 inch)
Cable
bearer
140 cm
(55.1 inch)
PIN-CODE
E2BA11 MNI1A7
Valid until 30-06-2018
pin.commend.com
