MAIN DISPLAY SLAVE MODE
The display shows Mode Slave
the delay time set in the master unit under the standalone operating modes Auto and Loop are
also displayed.
Mode
Slave
Gr 1 2.0s
CONFIGURE DMX START ADDRESS
Press MODE to access the main menu. Now use UP and DOWN to select the menu item DMX
Address and confirm with ENTER. You can now configure the DMX start address with UP and
DOWN. Confirm with ENTER and press MODE once to return to the main display. The main display
is activated automatically after approximately two minutes of no input.
--------Menu------- ----DMX Address----
DMX Address DMX Address
001–512
DMX Mode DMX Mode
DMX Delay DMX Delay
Standalone
Slave
Settings
System Info
CONFIGURE DMX MODE
Press MODE to access the main menu. Now use UP and DOWN to select the menu item DMX
Mode and confirm with ENTER. Again use UP and DOWN to select the desired DMX mode and
confirm with ENTER (DMX modes with DMX delay channel are marked with "D"). Press MODE
once to return to the main display. The main display is activated automatically after approximately
two minutes of no input. Tables with the channel assignment of the different DMX modes can be
found in these instructions under DMX CONTROL.
CLROOTPAR4
--------Menu-------
DMX Address ----DMX Address----
DMX Mode
DMX Address
001 - 512 001 - 512 001 - 512 2CH
DMX Delay
DMX Mode
4CH1
Stand Alone
DMX Delay
4CH2
Slave
5CH
Settings
6CH
System Info
9CH
DMX DELAY
The DMX Delay function allows a chaser light effect to be easily created with any number of
spotlights of the same model and software version, which could otherwise only be achieved with
a suitable DMX controller and complex programming. All spotlights integrated into the setup are
set to the same DMX mode and controlled with the same DMX start address.
If the slave unit is assigned to a slave group, the slave group and
.
CLROOTPAR6
----DMX Address----
DMX Address
D3CH 001 - 512 001 - 512 001 - 512
2CH D3CH
DMX Mode
D5CH1
4CH1 D5CH1
DMX Delay
D5CH2
4CH2 D5CH2
D6CH
5CH D6CH
D7CH
6CH D7CH
D10CH
8CH D9CH
11CH D12CH
