PowerMax cam unit SN5650-PMO-0330 — SN5650-PMO-1200
10.1.1 Mounting of the Lock-Out-System SN5651-LOS
To fasten the cam for the insertion of borings, the fixation of the cam slide by means of a lock-out system
is necessary. For this purpose please act as following.
picture 1
picture 2
1
18
STRACK NORMA GmbH & Co. KG · Königsberger Str. 11 · D-58511 Lüdenscheid · Tel +49 2351 8701-0 · www.strack.de
2
PowerMax
I
Operating instructions -- PowerMax cam unit PMO
1. Dismounting of the gas spring
2. Dismounting of the slide stop with the
damper
