FALMEC Quantum Gebrauchsanweisung Seite 21

Select the cooking area;
Touch (+) and then (-): the symbol will appear.
Shutdown of the cooker
To shutdown the cooking area:
Touch the key ( - ) until 0 is displayed on the screen of the cooking area.
If the cooking area is still too hot, the residual heat is specified
Turn off the cooker
Touch the key : all cooking areas are deactivated.
On the display of the cooking areas that are still too hot, the symbol is dis-
played .
Do not touch the cooking areas until the lamp
TIMER FUNCTION AND AUTOMATIC
SHUTDOWN FOR THE COOKER
The timer has two functions:
1 – TIMER;
2 – AUTOMATIC SHUTDOWN of one or more cooking areas.
It is possible to set a duration up to 99 minutes.
Once the time set is over, on the display regarding time 00 is shown and a
sound warning is activated that can be deactivated pushing keys (+) or (-).
TIMER
To set:
1. If off, turn the hob on using the
2. Set the desired time touching keys (+) and (-).
Timer starts passing.
To modify time repeat the procedure from point 1.
To cancel timer:
1. If off, turn the hob on and touch (+) and (-) at the same time.
(on the Plus version the lamp is on
2. Touch the key ( - ) to bring time to 00.
AUTOMATIC SHUTDOWN
For the automatic shutdown function:
1 - turn on the cooker;
2 - select the cooking area;
3 - select the level;
4 - set the timer as described above.
To set the automatic shutdown for another cooking area, repeat the proce-
dure from point 2.
TIMER and AUTOMATIC SHUTDOWN can be used simultaneously.
WHAT TO DO IN CASE OF COOKERS PROBLEMS
The cooker or cooking areas do not turn on:
•
The cooker is not connected to the electric network.
•
The protection fuse is released.
•
Check if the block is not active.
•
Keys are covered with water or grease.
•
An object is placed on the keys.
The symbol is displayed .
•
There is no saucepan on the cooking area.
•
The container used is not compatible with cooktops.
•
The diameter of the saucepan bottom is too small compared to the
cooking area.
The symbol [E] is displayed:
•
Disconnect and connect the cooker.
•
Contact the after-sales centre.
One of the area or the entire cooker turns off:
.
is on.
key and touch (+) and (-) at the same time.
).
•
The safety overheating system is active;
•
The cooker or one cooking area remains on for too long;
•
one or more keys are covered;
•
one of the saucepans is empty and the bottom overheated.
The fan keeps on working after the cooker shutdown:
•
This is not a malfunction: the fan keeps on protecting the electronic
power unit of the device.
•
The fan stops automatically.
COOKERS ERROR CODES
For supporting a service technician in case of error, the UI displays error co-
des.
In combination with the provided document "error codes Basic 2" which in-
cludes datailed information a complete error matrix description is available.
E.G.O's standard error codes are listed following, customized UI can be diffe-
rent. In the standard general UI eroors (Er xx) and cooking zone errors (E/x)
differ. In case of cooking zone errors the display of the incorrect cooking zone
blinks alternative "E" and a hexcode "X".
Error Description
code
The cooking zone
.
can be configu-
red if a static "C"
is shown
The cooking will
.
be configured
if a flashing "C"
is shown. After
a successful
configuration the
relevant display
shows "-". If "-"
is not displayed
check the pos-
sible causes of
the E/5
A flashing "E" on
.
each cooking
zone indicates
that all configs
will be deleted
Temperature limi-
.
ts are exceeded
Unsuitable pot,
.
e.g. loss of the
magnetic cha-
racteristics becau-
se of temperature
in the bottom
Unconfigured
. induction module
(all induction mo-
dule answer to UI,
but any element
is related to the
effected cooking
zone.)
21
possible Remedy
causes
No error, the A suitably pan must
user is in the be placed on the
service menu. relevant cooking
zone
User is in the Wait for the symbol
service menu, "-" or abort the confi-
no error guration activities by
pressing the select
key and the "C" will
not flash anymore.
User is in service Manual configura-
menu, no error tion
Pt or glass System must cool
temperature is down
too high
NTC -> electro-
nic temperature
too high
On the module 1. The error is auto-
a pot creates matically cancelled
an improper after 8 s and the
operatioing cooking zone can be
point which can used again. In case
destroy devices, of further upcoming
e.g IGBTs. errors the pot has to
be replaced.
2. The module has
to be changed if the
error comes without
a pot on the cooking
zone.
induction Delete the hob
module is not configuration and
configured activate the manual
configuration. Start
the UI service menu
to configure the
induction module if
the listed points are
not successful repla-
ce the module.
