English
4. Table saw operating procedure warnings
a) Turn off the table saw and disconnect the battery
pack when removing the table insert, changing
the saw blade or making adjustments to the riving
knife, anti-kickback pawls or blade guard, and
when the machine is left unattended.
Precautionary measures will avoid accidents.
b) Never leave the table saw running unattended.
Turn it off and don't leave the tool until it comes
to a complete stop.
An unattended running saw is an uncontrolled hazard.
c) Locate the table saw in a well lit and level area
where you can maintain good footing and balance.
It should be installed in an area that provides
enough room to easily handle the size of the
workpieces.
Cramped, dark areas, and uneven slippery floors invite
accidents.
d) Frequently clean and remove sawdust from under
the saw table and/or the dust collection device.
Accumulated saw dust is combustible and may self
ignite.
e) The table saw must be secured.
A table saw that is not properly secured may move or
tip over.
f) Remove tools, wood scraps, etc. from the table
before the table saw is turned on.
Distraction or a potential jam can be dangerous.
g) Always use saw blades with correct size and shape
(diamond versus round) of arbour holes.
Saw blades that do not match the mounting hardware
of the saw will run off-centre, causing loss of control.
h) Never use damaged or incorrect saw blade mounting
means such as flanges, saw blade washers, bolts
or nuts.
These mounting means were specially designed for
your saw, for safe operation and optimum performance.
i) Never stand on the table saw, do not use it as a
stepping stool.
Serious injury could occur if the tool is tipped or if the
cutting tool is accidentally contacted.
j) Make sure that the saw blade is installed to rotate
in the proper direction. Do not use grinding wheels,
wire brushes, or abrasive wheels on a table saw.
Improper saw blade installation or use of accessories
not recommended may cause serious injury.
k) Only use 10" saw blade with kerf width of 2.4mm
and blade body thickness is 1.6 mm match the
riving knife with thickness of 2.0 mm.
l) Always use only a saw blade diameter in accordance
with the markings on the saw; Use only saw blades
for which the maximum possible speed is not
less than the maximum spindle speed of the
product.
m)Do not use any blunt, cracked, deformed or
damaged saw blades. Only replace the saw blade
with one complying with the European standard
EN 847-1.
n) Do not store this tool with the battery installed.
Think through all scenarios to ensure that the saw is
never turned on accidentally.
o) Do not transport this tool with the battery or
adapter installed.
5. Additional safety instructions
• Please also observe the special safety instructions in the
respective chapters.
• Where applicable, follow the legal directives or regulations
for the prevention of accidents pertaining to the use of
table saws.
• Avoid overheating of the saw teeth.
• Do not attempt to stop the saw blade by pushing the
workpiece against its side.
• Store saw blade in such manner that nobody will get hurt.
• Before making a cut, be sure all adjustments are secure.
• Be sure blade path is free of nails. Inspect for and remove
all nails from lumber before cutting.
• Never touch blade or other moving parts during use.
• Make sure the work area has ample lighting to see the
work and that no obstructions will interfere with safe
operation before performing any work using the table saw.
• If this saw makes an unfamiliar noise or if it vibrates
excessively, cease operating immediately, turn unit off and
remove the battery pack until the problem has been
located and corrected. Contact a HiKOKI Authorized
Service Center if the problem can not be found.
CAUTION ON LITHIUM-ION BATTERY
To extend the lifetime, the lithium-ion battery equips with the
protection function to stop the output. In the cases of 1 to 3
described below, when using this product, even if you turn
the switch on, the motor may stop. This is not the trouble but
the result of protection function.
1. When the battery power remaining runs out, the motor
stops. In such case, charge it up immediately.
2. If the tool is overloaded, the motor may stop. In this case,
turn off the switch of tool and eliminate causes of overloading.
After that, you can use it again.
3. If the battery is overheated under overload work, the
battery power may stop. In this case, stop using the battery
and let the battery cool. After that, you can use it again.
Furthermore, please heed the following warning and caution.
WARNING
In order to prevent any battery leakage, heat generation,
smoke emission, explosion and ignition beforehand, please
be sure to heed the following precautions.
1. Make sure that swarf and dust do not collect on the battery.
- During work make sure that swarf and dust do not fall
on the battery.
- Make sure that any swarf and dust falling on the power
tool during work do not collect on the battery.
- Do not store an unused battery in a location exposed to
swarf and dust.
- Before storing a battery, remove any swarf and dust that
may adhere to it and do not store it together with metal
parts (screws, nails, etc.).
2. Do not pierce battery with a sharp object such as a nail,
strike with a hammer, step on, throw or subject the battery
to severe physical shock.
3. Do not use an apparently damaged or deformed battery.
4. Do not use the battery in reverse polarity.
5. Do not connect directly to an electrical outlets or car
cigarette lighter sockets.
6. Do not use the battery for a purpose other than those
specified.
7. If the battery charging fails to complete even when a
36
