Too short bolts are not able to hold the TV.
If you use too long bolts or screw them at an angle you may
break the TV.
TV

5. VESA panel installation

• Find out your TV's VESA pattern. You can do this either by checking
your TV's characteristics or by manual measuring distance between
holes on the back of your TV – horizontal and vertical. This is your
VESA pattern.
Width:_______mm/inches
UP
• IMPORTANT: Type of your TV will help to understand what spacers
and screw should be used.
8
TV
TV
x Height_______mm/inches
TV
100 mm = 10 cm = 4 inches
200 mm = 20 cm = 7.8 inches
300 mm = 30 cm = 11.8 inches
400 mm = 40 cm = 15.7 inches
TV
