Vacuuming (Fig. I):
Connect the suction hose (a) to the suction hose port (9). To do so, slide the end of the
suction hose (a) with the two nipples into the suction hose port (9) (A). Insert the two nipples
into the recesses. Once the suction hose is fully inserted, turn it clockwise (B).
Blowing (Fig. J):
Connect the suction hose (a) to the blowing function connection port (13). Slide the end
of the suction hose (a) with the two nipples into the blowing function connection port (13).
Insert the two nipples into the recesses. It is not necessary to turn it here.
Installing the metal extension tube (g), suction hose (a) and nozzles (e / f) (Fig. K)
• Connect the metal extension tube (g) with the bent end of the suction hose (a).
• Fit the floor nozzle (e) or joint nozzle (f) to the other end of the metal extension tube (g).
• Push the slide piece forwards (A) to change the length of the metal extension tube (g).
(Fig. L)
• Pull the tube to the desired length (B). Ensure that the slide lock latches into place. (Fig. L)

9. Operation

m WARNING!
Always make sure the device is fully assembled before start-up!
m WARNING!
Switch the device off if liquid or foam emerges with the exhaust air during wet vacuuming.
Switch on / switch off / automatic (Fig. M, N)
The ON/OFF switch (11) has three settings:
1. Switch setting 0: Off
2. Switch setting II: On
- Press the on/off switch (11) on position "II" tu turn on the device.
- Press the on/off switch (11) on position "0" to turn off the device.
3. Switch setting I: Automatic mode (the vacuum cleaner will be switched on by an electric
tool).
• Plug your electrical tool's cable into the automatic socket (10) (fig. N).
• Connect the suction hose (a) to the suction connection (9) on your electrical tool. Check
that the connection is secure and airtight.
• Set the switch on the vacuum system to position "I" = Automatic mode.
