Item description:
Remote bus:
Display elements:
Front panel controls:
Rear panel controls:
Inputs:
Input connections:
Outputs:
Output connections:
Speaker cable diameter
Expansion slots:
Cooling:
Operating voltage:
Mains fuse:
Inrush current OFF-standby:
Inrush current standby-ON:
Power consumption
in standby:
Power consumption
in sleep mode:
Power consumption
at full load:
Operating temperature:
Width:
Height:
Depth:
Weight:
Rack distance to the
next device (height):
Rack depth (required):
Output specifications for the speakers, all outputs driven and loaded
Output power
(1 kHz at 4 Ohm):
Output power
(1 kHz at 8 Ohm):
Output power
(1 kHz at 16 Ohm):
12
LDIPA424T
Back: 4 x input signal clip LEDs, remote lock LED (red).
Front: "PROT", "LIMIT", "SIG", "BRIDGE" and mute symbol LEDs Power On/Standby LED
Potentiometer for output volume. Amplifier channel mode: "PAR" (Parallel), "ST" (Stereo), "BRG" (Bridge).
Remote ON/OFF. Remote locking switch. Remote mode. Standby On/Off. Switch for preset A and B. Low-Z and
4 x balanced line inputs, remote bus audio input
6-pole terminal block, pitch 3.81 mm, remote ON/OFF RJ45, service connector micro USB type B
4 x powered speaker outputs: Low-Z (minimum 4 Ohm), high-Z (70 V and 100 V).
Fault detection: 2 x NO/NC relay outputs (connected).
Speaker outputs: 4-pole terminal block connections, pitch 5.08 mm.
Fault relays: 2 x 3-pole terminal block, pitch 3.81 mm.
Minimum diameter (max AWG) of cable cross section is 1.5 mm² (16 AWG)
Maximum diameter (min AWG) of cable cross section is 3.31 mm² (12 AWG)
Yes. For optional Ethernet or Ethernet + Dante cards
Passive + temperature-controlled active two-zone cooling, with airflow from front to back/to the side
30 W
1000 W
0 °C ... +40 °C (max. 60% relative humidity).
425 mm (with terminal block connections)
11.36 kg
4 x 240 W (1.5 second sine burst)
4 x 120 W (1.5 second sine burst)
4 x 60 W (1.5 second sine burst)
Yes
Standby, On/Off switch (Power On/Off)
high-Z switch (Per pair of channels).
100 – 240 V
T10AL/100-120 V; T5AL/220-240 V
2.8 A
0.5 A
0.9 W
19" rack (483 mm)
1 HE (44.5 mm)
1 HE
500 mm
4 x 120 W (1.5 second sine burst)
4 x 60 W (1.5 second sine burst)
4 x 30 W (1.5 second sine burst)
LDIPA412T
25 W
790 W
8.7 kg
