GB
A. Installing
• IMPORTANT! Make sure the Isofix connectors are retracted.
16 • Press the central button on the support leg (16,1) and pull the support leg forward as far as possible
(16,2).
• IMPORTANT! Secure any fold-down seats.
• IMPORTANT! On some seats, the belts are fitted so far forward that proper installation is not possible.
If this is the case, try another seat (see section 9: Car fitting list).
17 • Place the EasyFix on the seat of the car (17) with the support leg folded out.
18 • Open the blue belt clamp by pulling the lever up (18,1). Pass the shoulder and lap belt together through
the belt opening (18,2).
• Pass the seat belts between the base and the blue belt clamp and then through the second belt
19
opening (19,1).
• Insert the seat belt into the belt buckle of the car (19,2).
19
• NOTE! Make sure that the seat belt is pulled tight and is not twisted.
• Fasten the belt clamp by pushing the lever down (20).
20
• Check that it is fastened correctly by pulling on the EasyFix.
B. Adjusting the length of the support leg
• See section 3.1, point C: "Adjusting the length of the support leg".
Checklist ...
To ensure the optimum safety of your child, check the following after installation:
• The seat belt is as tight as possible and not twisted.
• The two belt parts pass through the belt openings in the base and under the blue belt clamp.
• The support leg is fully folded out.
• The indicator at the base of the support leg is completely green.
• In some cases the EasyFix may not be fully supported by the car seat, but entirely by the support leg.
• The EasyFix as a whole has been installed in the car in a secure and stable manner by pulling on the
EasyFix.
C. Removing the EasyFix
• Restore the support leg to its start position by pressing the control button (21,1) and sliding the support
21
leg upwards (21,2).
• Loosen the seat belt (22,1) and open the blue belt clamp (22,2).
22
14
