Operational functions

Digital filter setting

Press the key for 3 seconds to access the digital filter settings.
▲ Increase filter
Confirm and return to normal operation
▼ Decrease filter
When you are inside the filter setting function, the LEDs are both lit
Pressing the ▲ key the weight filter is increased (selectable from 0 to 9).
Pressing the ▼ key the weight filter is decreased (selectable from 0 to 9).
Whent the weight filter is changed by pressing one of those two keys, the LED no. 1 remains on steadily
while LED 2 is blinking a number of times equal to the selected filter. In case the filter is zero, both LED's
are flashing.

Zero offset correction of the analog output

With the scales empty, press ▼ (long pess) to access the analog zero offset correction.
When you are inside the zero offset correction function, the LED no. 1 is flashing
off .
Pressing the ▲ key increases the zero offset of the analog output. With a long press, a rough correction of
the offset is performed, while a fine correction is performed with short pressure .
Pressing the key (short press) the analog output is positioned close to zero.
Pressing the ▼key decreases the zero offset of the analog output. With a long press, a rough correction of
the offset is performed, while a fine correction is performed with short pressure .
Press the key (long press) to exit this function.
Span offset correction of the analog output
With the scales empty, press ▲ (long pess) to access the analog span offset correction.
When you are inside the zero offset correction function, the LED no. 1 is off
ing .
Pressing the ▲ key increases the span offset of the analog output. With a long press, a rough correction of
the offset is performed, while a fine correction is performed with short pressure .
Pressing the ▼key decreases the span offset of the analog output. With a long press, a rough correction of
the offset is performed, while a fine correction is performed with short pressure .
Press the key (long press) to exit this function.
Pagina – page – Seite 14
.
while the LED no. 2 is
while the LED no. 2 is flash-
