Installation manual
Technical specification
Power supply
Maximum power consumption
Insulation
Installation category
Storage temperature
Operating temperature
Humidity
LED
Keyboard
Overall dimensions
Installation
Material of housing
Wire connections
Load cells input
Power supply cells
Linearity
Internal resolution
Temperature deviation
Measuring range
Digital filter
Weight decimals
Calibration Zero and full scale
Cell cable break check
Analog exit in tension
Resolution
Calibration
Impedance
Linearity
Temperature deviation
Analog exit in current
Resolution
Calibration
Impedance
Linearity
Temperature deviation
Compliance to EMC norms
Compliance electric safety
24 V direct current ± 10 % protected against inversion of polarity.
Protection resettable fuse
1 Watt
Class II
Category II
-4 °F / 140 °F
14 °F / 122 °F
maximum 85% non-condensing
2 LED with 3 mm (function status)
3 keys (behind red front cover)
4.33 x 4.72 x 0.90 in including terminal blocks
Support for DIN or OMEGA rail
Blend ABS/PC self-extinguishing
Removable screw terminals, pitch terminal blocks 5,08 mm
Maximum 4 load cells with 350 Ω in parallel (or 8 cells with 700 Ω)
4 Volt direct current
0,01 % of full scale
16 – 24 bit
< 0,001 % of full scale/°C
From -2,6 mV/V to +2,6 mV/V
Selectable 0.1 Hz – 50 Hz
from 0 to 3 decimal numbers
executable through buttons
always present
± 10 V / ± 5 V
16 bit
digital through buttons
≥ 10 kΩ
0,03 % of full scale
< 0,002 % of full scale/°C
0 – 20 A / 4 – 20 mA
16 bit
digital through buttons
≤ 300 Ω
0,03 % of full scale
< 0,002 % of full scale/°C
EN61000-6-2, EN61000-6-3
EN61010-1
