User manual

Main characteristics of use

The main operating features are the management of an analog output, the output can be either in Volt or in
mA.

Front panel of the instrument

LED indicators

The instrument is equipped with two LED indicators:
LED 1
On Off
Flashing Off
Off Flashin
On On
Fast flashing Fast flashing

Use of the keyboard

The instrument is programmed and controlled by the keyboard consisting of three keys:
Key
(Long press) allows you to access the setting of the analogue output value that you want to
▲
have at the output with the weight present on the scale
(Long press) Access to the digital filter setting function
▼ (Long press) Enters in the zero offset correction function of the analog output
LED 2
Normal operation
Zero offset correction function of the analog output in execution
Span offset correction function of the analog output in execution
Digital filter setting function in execution
Weight signal absent or outside the reading range
Key function
