Remove any build-up of grass on or around the drive shaft
and the motor fan (do not use water). Wipe the mower
clean with a damp cloth.
REMOVING/INSTALLING THE BLADE
WARNING:
Always protect your hands by wearing
heavy gloves or wrapping the cutting edges with rags or
other materials when performing any maintenance on
the mower blade. Always remove the battery pack when
servicing or transporting the mower.
◾
To Remove the Blade
Following Fig. R1.
NOTICE:
If the bolt rotates with the motor shaft when
loosening the bolt, turn the fan by hand to align the
through holes in the fan with the holes in the blade,
and place another metal rod into the aligned holes
(Fig. R2).
◾
To Install the Blade
Following the assembly sequence in Fig. S, with the
fan blade towards deck and the printed blade side
towards outside, align the through holes in the fan
with the holes in the blade (Fig. T) and then tighten the
blade as Fig. U shown.
Fig. R2 & S parts description see below:
R2-1 Stabilizer 1 S-2
R2-2 Stabilizer 2 S-3
R2-3 14mm Wrench S-4
S-1 Fan S-5
NOTICE:
The recommended torque for tightening the
blade bolt is 49-59Nm.
STORING THE MOWER
◾
Remove the battery pack from the mower and store it
in a cool, dry and clean location. Do not store it next to
corrosive materials, such as fertilizer or rock salt.
◾
Store the mower in a covered, enclosed space, that is
cool and dry and out of the reach of children.
◾
Do not cover the lawn mower with a solid plastic sheet.
Plastic coverings trap moisture around the mower,
which causes rust and corrosion.
◾
The mower can be stored upright or flat. (Fig. V & W).
WARNING:
If the mower tips over from the upright
position, mower damage or personal injury may result.
Always keep the mower stable and out of the reach of
children when it is in the upright position. If possible, lay it
flat for storage.
56 VOLT LITHIUM-ION CORDLESS MOWER — LM1700E/LM1700E-SP

Protecting the environment

Inner Flange
Blade
Outer Flange
Bolt
Do not dispose of electrical equipment,
battery charger and batteries/
rechargeable batteries into household
waste!
According to the European law
2012/19/ EU, electrical and electronic
equipment that is no longer usable, and
according to the European law
2006/66/EC, defective or used battery
packs/batteries, must be collected
separately.
If electrical appliances are disposed of in
landfills or dumps, hazardous substances
can leak into the groundwater and get into
the food chain, damaging your health and
well-being.
