Tab. 60:
Id Attribute
0x6 Cable Test Result
6
UM Config OCTOPUS
Release 8.4 09/2020
Hirschmann-Erweiterungen des TCP/IP-Interface-Objekts (Forts.)
Access
Rule
Get
Data type
STRUCT of:
USINT Interface
USINT CablePair
USINT CableStatus
USINT
CableMinLength
USINT
CableMaxLength
USINTCableFailureL
ocation
Industrieprotokolle
15.3 EtherNet/IP
Description
100BASE:{
{Interface, CablePair1,
CableStatus, CableMinLength,
CableMaxLength,
CableFailureLocation}
{Interface, CablePair2,
CableStatus, CableMinLength,
CableMaxLength,
CableFailureLocation}
}
1000BASE:{
{Interface, CablePair1,
CableStatus, CableMinLength,
CableMaxLength,
CableFailureLocation}
{Interface, CablePair2,
CableStatus, CableMinLength,
CableMaxLength,
CableFailureLocation}
{Interface, CablePair3,
CableStatus, CableMinLength,
CableMaxLength,
CableFailureLocation}
{Interface, CablePair4,
CableStatus, CableMinLength,
CableMaxLength,
CableFailureLocation}
}
