Industrieprotokolle
15.3 EtherNet/IP
15.3.2

EtherNet/IP-Entity-Parameter

Die folgenden Absätze identifizieren die Objekte und Operationen, die das Gerät unterstützt.
Unterstützte Operationen
Tab. 56:
Service Code
0x01
Get Attribute
All
0x02
Set Attribute All
0x0e
Get Attribute
Single
0x10
Set Attribute
Single
0x05
Reset
0x35
Save
Configuration
Vendor specific
0x36
Mac Filter
Vendor specific
0x4B
Verify Fault
Location
358
Übersicht über die unterstützten Etnernet/IP-Requests für die Objektinstanzen.
Identity TCP/IP
Object Interface
Object
All All
attributes attributes
– Settable
attributes
(0x3, 0x5,
0x6, 0x8,
0x9, 0xA)
All All
attributes attributes
– Settable
attributes
(0x3, 0x5,
0x6, 0x8,
0x9, 0xA,
0x64)
Parameter –
(0x0, 0x1)
– –
– –
Ethernet Switch Agent
Link Object Object
All All attributes
attributes
Settable –
attributes
(0x6, 0x9)
All All attributes
attributes
Settable Settable
attributes attributes (0x5,
(0x6, 0x9, 0x7)
0x65, 0x67,
0x68, 0x69,
0x6C)
– –
– Save switch
configuration
– Add MAC filter
STRUCT of:
USINT VlanId
ARRAY of:
6 USINT
Mac
DWORD
PortMask
Base DLR Object
Switch
Object
All All attri-
attributes butes
(except attri-
1
bute 0x9)
– –
All All attributes
attributes
– Settable
attributes
(0x4, 0x5)
– –
– –
– –
Verify fault
location
