Hirschmann OPUS-IPv6 Referenzhandbuch Seite 876

Tab. 59:
Id Attribute
0x1 Status
0x2 Interface Capability
flags
0x3 Config Control
0x4 Physical Link Object Get
0x5 Interface
Configuration
0x6 Host Name
0x7 Safety Network
Number
0x8 TTL Value
UM Config OCTOPUS
Release 8.4 09/2020
Attribute der Instanz 1
Access
Rule
Get
Get
Set/Get DWORD
Set/Get STRUCT of:
Set/Get STRING
Get/Set USINT
Data type
DWORD
DWORD
STRUCT of:
UINT PathSize
EPATH Path
UDINT IpAddress
UDINT Netmask
UDINT
GatewayAddress
UDINT NameServer1
UDINT NameServer2
STRING DomainName
Industrieprotokolle
15.3 EtherNet/IP
Description
0: Interface Status
(0=Interface not configured,
1=Interface contains valid
config)
6: ACD status (default 0)
7: ACD fault (default 0)
0: BOOTP Client
1: DNS Client
2: DHCP Client
3: DHCP-DNS Update
4: Configuration setable (within
CIP)
Other bits reserved (0)
7: ACD capable (0=not capable,
1=capable)
0: 0x0=using stored config
0x1=using BOOTP
1:
0x2=using DHCP
2:
3:
4: 1 device uses DNS for name
lookup (always 0 because it is
not supported)
Other bits reserved (0)
Path to the Physical Link Object,
always {0x20, 0xF6, 0x24, 0x01}
describing instance 1 of the
Ethernet Link Object.
IP Stack Configuration (IP-
Address, Netmask, Gateway, 2
Name servers (DNS, if supported)
and the domain name).
Host Name (for DHCP DNS
Update)
Not supported
Time to live value for IP multicast
packets Range 1..255 (default =
1)
361
