TLS QuickControl XL is a multifunctional room control system for
small and mid-size conference rooms. QuickControl XL trasmits
control commands over long distances via IR commands and RS232
protocols to playback and display devices and controls via I/O
contacts connected screens, ceiling lifts and similar media techno-
logial devices.
QuickControl XL can be mounted space-saving in wall or integrated
in every table installation module. With each button at QuickControl
XL 8 functions can be executed simultaneously. With 8 internal and 2
optionally connectable external buttons a total of up to 80 functions
can be executed in that way.
The labelling of QuickControl XL can be done according to
individual needs.
QuickControl XL can be easily configurated via itsConfiguration
Tool,
The integrated GreenLine function of QuickControl XL diconnects
automatically all connected devices after the presentation from the
230 V~/110 V~ mains and puts all devices back into their initial state.
Thus this room control system helps to save energy costs and to
extend the devices' life cycle.
