Technical Parameters

Level 2 EV Charging Station
Mode: C(with plug)
16/32A
3.84/7.68KW
Warraty: 1 Year
1
Distribution Box
Make sure the wallbox is connected to power
◆Hang the cable on the hook when it is not in use
Instruction for Use
Wall
Charging Station
Button
Holder
Charging Plug
Hook
Phase Mode: Three Phase
Mode: C(with plug)
Rated Voltage: 380VAC±10%
Rated Current: 16/32A
Maximum Power: 11/22KW
Enclosure Material: ABS+PC alloy
Warraty: 1 Year
2
Connect the EV and the wallbox
with the EV charging cable
3
of the wallbox to start/stop charging
25℃ +55℃
