Wallbox Mode C Bedienungsanleitung Seite 5

Level 2 EV Charging Station
Mode: A(with outlet)
16/32A
3.84/7.68KW
Warraty: 1 Year
Distribution Box
Make sure the walbox is connected to power
to start/stop charging
◆Hang the cable on the hook when it is not in use
Technical Parameters
Instruction for Use
Wall
Charging Station
Button
Hook
Charging Plug
Phase Mode: Three Phase
Mode: A(with outlet)
Rated Voltage: 380VAC±10%
Rated Current: 16/32A
Maximum Power: 11/22KW
Enclosure Material: ABS+PC alloy
Warraty: 1 Year
Insert the plug into socket
Connect the EV and the wallbox
with the EV charging cable
25℃ +55℃
