Greenlinkbox SLT.22
2.9.3 Installation Greenlinkbox SLT.22 via RS-232 with Modem
Remote:
1. Ensure all equipment is voltage free (Greenlinkbox SLT.22 and modem).
2. Check if all connections and settings (dipswitches) are correct.
3. Switch on the modem.
4. Switch on the Greenlinkbox SLT.22.
PC location:
1. Start the F-Central program on your PC and choose the red toolbox /
install control units.
2. Enter the COM-gate number to which the modem is connected, in F-
Central route settings. Check off option Modem and enter the telephone
number.
3. Installation of Greenlinkbox SLT.22 for PC and F-Central completed.
2.10 Functioning and diagnosis
The following diagnosis LEDs can be used to test the Greenlinkbox SLT.22:
Colour Status
Red OFF
ON
OFF
Yellow
ON
Green OFF
ON
Flashing
Function
Supply voltage not present
Supply voltage present
Incorrect connection between the
Greenlinkbox SLT.22 and an active F-Central.
Correct connection between Greenlinkbox SLT.22 and
an active F-Central.
No controls found on FNet or FLoop.
Control(s) found on FNet or correct Baudrate found on
FLoop.
No communication yet with F-Central.
Control(s) found on FNet or correct Baudrate found on
F-Loop.
Communication with F-Central via FNet or FLoop.
2.10 Functioning and
diagnosis
GB-12
