Greenlinkbox SLT.22
1.7 Greenlinkbox SLT.22 aansluitpunten, indicaties en selecties
1
Figuur 4: Aansluitpunten Greenlinkbox SLT.22
Item Aansluitpunt /
Indicatie / setting
1
Voedings adapter
2
Diagnose LED's
3
FLoop en FNet
4
Dipswitches
5
RS-232
6
USB
2
3
Omschrijving
Voedingsvoorziening Greenlinkbox SLT.22
Indicatie voor voeding en
communicatie verbindingen
Aansluitpunten proces netwerken
Keuze mogelijkheid diverse situaties
Aansluitpunt PC of Modem
Aansluitpunt PC
1.7 GreenLinkBox aansluit-
punten, indicaties en
selecties
4
5
NL-6
6
