Greenlinkbox SLT.22
2.7 Greenlinkbox SLT.22 connections, LEDs and selections
1
Fig. 13: Connection points Greenlinkbox SLT.22
Item Connection
LEDs / setting
1
Power adapter
2
LED diagnosis
3
FLoop and FNet
4
Dipswitches
5
RS-232
6
USB
2
3
point
/
Description
Power supply Greenlinkbox SLT.22
LED for power supply and
communication connections
Connection points process networks
Options for various situations
Connection point PC or Modem
Connection point PC
2.7 GreenLinkBox
connections LEDs and
selections
4
5
GB-6
6
