OPERATING INSTRUCTIONS
IN-CAR CHARGER
ITEM NO.: 44 88 80 CLC-4800USB
ITEM NO.: 44 88 81 CLC-2400S
ITEM NO.: 44 88 90 CLC-2000USB
INTENDED USE
The product is suitable for charging and operating apple devices with 8-pole Lightning
connector. The additional USB port is intended for charging and operating USB devices
(only applicable for item no. 44 88 80 + 44 88 90). Power is supplied via an on-board voltage
socket. The product features overload and short circuit protection mechanisms. Use the
product in dry indoor areas only.
For safety and approval purposes (CE), you must not rebuild and/or modify this product. If
you use the product for purposes other than those described above, the product may be
damaged. In addition, improper use can cause hazards such as short circuiting, fire, electric
shock etc. Read the instructions carefully and keep them. Make this product available to third
parties only together with its operating instructions.
This product complies with the statutory national and European requirements. All company
names and product names are trademarks of their respective owners. All rights reserved.
DELIVERY CONTENT
• In-car charger
• Operating instructions
SAFETY INSTRUCTIONS
Read the operating instructions carefully and especially observe the safety
information. If you do not follow the safety instructions and information
on proper handling in this manual, we assume no liability for any resulting
personal injury or damage to property. Such cases will invalidate the
warranty/guarantee.
a) Persons / Product
• The device is not a toy. Keep it out of the reach of children and pets.
• Do not leave packaging material lying around carelessly. These may become
dangerous playing material for children.
• Protect the product from extreme temperatures, direct sunlight, strong jolts, high
humidity, moisture, flammable gases, vapours and solvents.
• Do not place the product under any mechanical stress.
• If it is no longer possible to operate the product safely, take it out of operation and
protect it from any accidental use. Safe operation can no longer be guaranteed if
the product:
- is visibly damaged,
- is no longer working properly,
- has been stored for extended periods in poor ambient conditions or
- has been subjected to any serious transport-related stresses.
• Please handle the product carefully. Jolts, impacts or a fall even from a low height
can damage the product.
• Also observe the safety and operating instructions of any other devices which are
connected to the product.
• Always turn the connected appliance off before connecting or disconnecting it.
• Disconnect the in-car charger when not in use.
• The product gets hot during use. Ensure sufficient ventilation and never cover the
product during use.
• Do not short-circuit the outputs.
• Make sure the cable does not get squeezed, bent or damaged by sharp edges.
• Never use the product immediately after it has been brought from a cold room
into a warm one. The condensation generated could destroy the product. A wall
plug transformer also poses the risk of fatal injury due to electric shock! Allow the
device to reach room temperature before connecting and using it. This may take
several hours.
b) Miscellaneous
• Consult an expert when in doubt about operation, safety or connection of the
device.
• Maintenance, modifications and repairs are to be performed exclusively by an
expert or at a qualified shop.
If you are not sure about the correct connection or use, or if questions arise which are not
covered by these operating instructions, please do not hesitate to contact our technical
support or another qualified specialist.
Voltcraft®, Lindenweg 15, D-92242 Hirschau, Tel. +49 96 04 / 40 87 80
OPERATION
Always switch off the desired device before connecting it to the respective
port on the in-car charger. Make sure the connection is correct. If the product
is not connected properly, it could overheat or cause an electric shock or fire.
Make sure your device matches the power supply data of the in-car charger.
Observe the information in chapter "Technical data".
1. When switched off, connect the apple device to the Lightning connector on the in-car
charger.
VERSION 07/13
2. When switched off, connect the USB device to the USB port on the in-car charger (only
applicable for item no. 44 88 80 + 44 88 90).
3. Connect the in-car charger to a voltage socket in your car. The power indicator of the in-car
charger lights up indicating the product is ready for use.
4. The connected appliance(s) will then be charged. If you want to use the connected
appliance(s) you may now switch it/them on.
5. Switch off the connected device before disconnecting the in-car charger from the vehicle
voltage socket.
6. Disconnect the in-car charger from the cigarette lighter after use.
You may use the in-car charger with the engine running or off. You should, however,
not start the engine when the in-car charger is connected, as the vehicle voltage socket
disconnects during engine start (not necessarily applicable for all vehicle types). If the
engine is switched off, drawing current over a longer period of time will discharge the
vehicle battery.
CLEANING
Disconnect the product from the on-board voltage socket before cleaning. Clean the product
with a dry, fiber-free cloth.
DISPOSAL
Electronic devices are recyclable waste and must not be disposed of in the
household waste.
At the end of its service life, dispose of the product according to the relevant
statutory regulations.
You thus fulfil your statutory obligations and contribute to the protection of the environment.
TECHNICAL DATA
Input voltage ....................................... 12 V/DC
Output voltage .................................... 5 V/DC
Operating temperature/humidity ......... -10 to +40 ºC, 20 – 90 % RH (non-condensing)
Storage temperature/humidity ............ -20 to +60 ºC, 10 – 90 % RH (non-condensing)
Cable length ....................................... 1 m
Output current ..................................... 2 x 2.4 A (item no. 44 88 80)
............................................................
............................................................
Dimensions (W x H x D) ..................... 25 x 25 x 69 mm (item no. 44 88 80)
............................................................
Weight ................................................ 42 g (item no. 44 88 80)
............................................................
............................................................
Legal notice
These operating instructions are a publication by Voltcraft®, Lindenweg 15, D-92242 Hirschau/Germany, Phone +49 96 04 / 40 87 80
(www.voltcraft.de).
All rights including translation reserved. Reproduction by any method, e.g. photocopy, microfilming, or the capture in electronic data processing
systems require the prior written approval by the editor. Reprinting, also in part, is prohibited.
These operating instructions represent the technical status at the time of printing. Changes in technology and equipment reserved.
© Copyright 2013 by Voltcraft®
2.4 A (item no. 44 88 81)
2 A total (item no. 44 88 90)
23 x 25 x 44 mm (item no. 44 88 81 + 44 88 90)
26 g (item no. 44 88 81)
28 g (item no. 44 88 90)
