Montage | Assembly
CONTI Sanitärarmaturen GmbH | Hauptstraße 98 | 35435 Wettenberg | Deutschland | Tel. +49 641 98221 0 | Fax +49 641 98221 50 | info@conti.plus
www.conti.plus | Druckfehler und Irrtümer sowie technische und maßliche Änderungen vorbehalten. | Errors and technical changes remain reserved.
Haube mit montiertem Haltewinkel unten an Rück-
1.
wand einhängen und mit Muttern lose sichern.
Nicht fest anziehen!
Hook the cover onto the rear wall with the lower
bracket mounted and secure loosely with nuts.
Do not tighten!
Haube mit Wasserwaage ausrichten und untere
2.
Befestigungspunkte einzeichnen.
Align the cover with a spirit level and mark the lower
fastening points.
Ø 8 mm
2x
