5 . 1 - O P E N I N G T H E C H A I N W I T H C - L I N K
- Insert the false link opening tool
with teeth less than 1.8 mm thick
into the inner links adjacent to the
(Fig. 10).
C-Link
™
- Compress the C-Link
both sides (inner and outer) and simul-
taneously operate the callipers to bring
the two pins closer together (Fig. 11).
ENGLISH
5 - O P E N I N G T H E C H A I N
by pushing on
™
C A M PA G N O L O . C O M
( C O N N E C T I N G L I N K )
™
Fig.10
Fig.11
