Maintenance; Storage; Disposal And Recycling - Scheppach RT450 Original Bedienungsanleitung

• The line trimmer may only be used for cutting grass
and weeds underneath bushes, on edges, corners
and slopes which cannot be reached by a lawn-
mower. Alternative use not specified in these in-
structions can damage the device or severely injure
the user. Therefore, it is explicitly excluded from the
list of possible applications.
Automatic thread feeding
The thread is automatically added during operation
by means of the centrifugal force. If a thread breaks
off, you can manually pull the thread out again.
Please disconnect the power plug from the mains
beforehand to avoid injuries.
Press the button (A / Fig.2) and pull on both ends
of the thread to achieve your desired thread length.
Should one of the thread ends be too long, the thread
is cut to the correct length by the integrated knife in
the plate.

9. Maintenance

The appliance must always be switched off be-
fore any servicing and cleaning. Wait until it fully
stops. Unplug it.
Servicing works not specified in these Operating In-
structions must be performed by authorised staff as
there may be dangerous situations the operator is
unable to handle. Spare parts may only be replaced
by authorised staff.
Cleaning
• Every time the appliance has been used, it should
be cleaned by a clean cloth, brush or blown with
compressed air under low pressure.
• Do not use cleaning agents and solvents as they
may damage the plastic parts of the appliance.
• Do not spray on the grass trimmer.
Changing the spool Fig. 2
CAUTION! Before changing the spool (B) Unplug
the power plug!
1. Press the two locking catches to open the cover
(C)
2. Remove the empty spool
3. Insert the new spool
4. Make sure that the spring is re-inserted
5. Put on the cover (C) and engage the locking
catches.
During the first start-up of the cutting head the thread
will be cut to the correct length by the knife on the
guard.
Now you can restart the machine.
 www.scheppach.com /  service@scheppach.com /  +(49)-08223-4002-99 /  +(49)-08223-4002-58
Service information
Please note that the following parts of this product
are subject to normal or natural wear and that the fol-
lowing parts are therefore also required for use as
consumables.
Wear parts*: carbon brushes, blade
* Not necessarily included in the scope of delivery!

10. Storage

Storage
• Disconnect the grass trimmer from the electricity
supply when it is not being used.
• Oil the blades to prevent rust
• Store the device in a dry place beyond the reach
of children.
• When the device is not being used, store it so it
cannot be started by unauthorised persons.
WARNING!
Do not store the device without protection outside or
in a damp environment.

11. Disposal and recycling

The equipment is supplied in packaging to prevent it
from being damaged in transit. The raw materials in
this packaging can be reused or recycled. The equip-
ment and its accessories are made of various types
of material, such as metal and plastic. Defective
components must be disposed of as special waste.
Ask your dealer or your local council.
Old devices must not be disposed of with house-
hold waste!
This symbol indicates that this product must
not be disposed of together with domestic
waste in compliance with the Directive
(2012/19/EU) pertaining to waste electrical
and electronic equipment (WEEE). This product must
be disposed of at a designated collection point. This
can occur, for example, by handing it in at an author-
ised collecting point for the recycling of waste elec-
trical and electronic equipment. Improper handling
of waste equipment may have negative consequenc-
es for the environment and human health due to po-
tentially hazardous substances that are often con-
tained in electrical and electronic equipment. By
properly disposing of this product, you are also con-
tributing to the effective use of natural resources.
You can obtain information on collection points for
waste equipment from your municipal administration,
public waste disposal authority, an authorised body
for the disposal of waste electrical and electronic
equipment or your waste disposal company.
GB | 25
