INTRODUCTION

7x 4 W RGBW PAR spotlights
CLROOTPAR4 (black housing)
CLROOTPAR4WH (white housing)
6x 12 W RGBWA+UV PAR spotlights
CLROOTPAR6 (black housing)
CLROOTPAR6WH (white housing)
CONTROL FUNCTIONS
CLROOTPAR4: 3-channel, 5-channel 1, 5-channel 2, 6-channel, 7-channel and 10-channel DMX control
CLROOTPAR6: 3-channel, 5-channel 1, 5-channel 2, 6-channel, 7-channel, 9-channel and 12-channel DMX control
Master/slave operation
Standalone functions
Control via IR remote control (remote control available optionally)
W-DMX connection via optional iDMX stick
FEATURES
3-pin DMX connections. Power Twist mains connections IN and OUT. OLED display. Adjustable PWM frequency. Connection for iDMX stick.
Convection cooling. Tilt adjustment screw. Installation double bracket included. Operating voltage 100–240 V AC.
CLROOTPAR4
7x 4 W RGBW LEDs. Power consumption 38 W.
CLROOTPAR6
6x 12 W RGBWA+UV LEDs. Power consumption 58 W.
