Cameo ROOT PAR 4 Bedienungsanleitung Seite 122

Sound
4 (triggers Strobe, Color Jump-
ing & Fading)
5 DMX Delay
ROOT PAR 6
Ch. Function
1 Red
2 Green
3 Blue
4 White
5 DMX Delay
ROOT PAR 6
Ch. Function
1 Dimmer
2 Strobe
3 Chase of Ch 4 and Ch 5
122
000 - 005 Sound Control off
Sound Control on, mic sensitivity low ->
006 - 255
high
000 - 005 No Delay
006 - 255 0,1s -> 2,0s
5-Channel Mode 2 (compatibility mode for ROOT PAR 4)
Values
000 - 255 0% to 100%
000 - 255 0% to 100%
000 - 255 0% to 100%
000 - 255 0% to 100%
000 - 005 No Delay
006 - 255 0,1s -> 2,0s
6-Channel Mode
Values
000 - 255 0% to 100%
000 - 005 Strobe open
006 - 255 Strobe slow -> fast <1Hz - 20Hz
000 - 005 No Chase, Color Preset 1 is on
006 - 026 Jump 10,0s -> 4,0s
027 - 127 Jump 4,0s -> 0,1s
128 - 148 Fade 10,0s -> 4,0s
149 - 255 Fade 4,0s -> 0,1s
Sound
DMX Delay
Sub-Group
Red
Green
Blue
White
DMX Delay
Sub-Group
Dimmer
Strobe
Chase
