Invacare Aquatec 90 Gebrauchsanweisung Seite 4

Aquatec® 90
90 has a unique height of 10 cm with or without a lid. It is
fixed with a clamp system at the rear of the toilet bowl.
9 Intended Use
This product is intended to be used as an aid for self-hygiene
care and toilet purposes by users who have limited function
in their legs. The seating height on the toilet is increased by
the product. Therefore, it provides additional support for
sitting down or standing up from a toilet seat and is installed
on standard toilet bowls.
Indication
Restricted or limited mobility (e.g.: legs and/or hips) or
having balance issues to stand up or walk due to transitional
or permanent disabilities.
There are no contraindications known when using the
product as intended.
The maximum user weight is 225 kg.
10 Setup (Fig. 3 – 5)
1. Slide the fixing elements into the allocated cavity on the
corpus. Twist the star screw just enough until the fixing
element takes hold. (Fig. 3)
2. Flip up your toilet seat. (Fig. 4) (Alternative: Remove
toilet seat)
3. Place the toilet seat raiser on the toilet bowl. (Fig. 4)
4. Push backward until the stop lug aligns with the toilet
bowl. (Fig. 4)
5. Tighten the star screws. (Fig. 4)
WARNING!
Risk of Falling
– Before each use, check that the fixing elements
are securely fastened and the corpus sits firmly
on the toilet.
To remove the lid: Press the snap-fits on both hinges
and release the lid from its corpus. (Fig. 5)
To install the lid: Slide the flaps into the desired
intake on the back of the toilet seat raiser. (Fig. 5)
11 Maintenance
11.1 General Maintenance Information
This product is maintenance-free, provided that the cleaning
and disinfection instructions are adhered to.
11.2 Cleaning and Disinfection
General Safety Information
CAUTION!
Risk of Contamination
– Take precautions for yourself and use
appropriate protective equipment.
4
IMPORTANT!
Wrong fluids or methods can harm or damage
the product.
– All cleaning agents and disinfectants used must
be effective, compatible with one another and
must protect the materials they are used to
clean.
– Never use corrosive fluids (alkalines, acid etc.)
or abrasive cleaning agents. We recommend
an ordinary household cleaning agent such as
dishwashing liquid, if not specified otherwise in
the cleaning instructions.
– Never use a solvent (cellulose thinner, acetone
etc.) that changes the structure of the plastic
or dissolves the attached labels.
– Always make sure that the product is completely
dried before taking it into use again.
For cleaning and disinfection in clinical or long-term
care environments, follow your in-house procedures.
Cleaning Intervals
IMPORTANT!
Regular cleaning and disinfection enhances
smooth operation, increases the service life and
prevents contamination.
Clean and disinfect the product
– regularly while it is in use,
– before and after any service procedure,
– when it has been in contact with any body
fluids,
– before using it for a new user.
Cleaning Instructions
IMPORTANT!
– Clean by hand
– Maximum cleaning temperature 60 °C
1. Clean the product by wiping down all generally accessible
surfaces.
2. Dry the parts with a cloth.
Cleaning in a Clinical Environment
In addition to cleaning as described above we
recommend cleaning the product prior to the use by
another patient, after ending of the period of use or
on a regular basis (depending on which occurs first) at
• 90 °C for 1 minute
• 85 °C for 3 minutes
• 80 °C for 10 minutes
in the autoclave.
CAUTION!
Risk of Burning Skin
– Allow the product to cool after cleaning in the
washing machine or autoclave.
Disinfection Instructions
Method: Follow the application notes for the used
disinfectant and wipe-disinfect all accessible surfaces.
Disinfectant: Ordinary household disinfectant.
Drying: Allow the product to air-dry.
12 Disposal
Be environmentally responsible and recycle this product
through your recycling facility at its end of life.
16223-D
