L5QA2/XE, XE2, L7QA2/XE, XE2 GB 2002, 7, 25
ADJUSTMENT

Lens adjustment

English
Downloaded from www.Manualslib.com
Horizontal & Vertical
Adjustment Screw
Gimbal Bracket
Angular Limit
Horizontal &
Vertical
Tilt
Adjustment
Tilt Adjustment Screws
Camera Lens -
Perpendicular Direction
Adjustment Screws
(K)
for Camera Rotation
Gimbal Bracket
Camera Rotation
5
manuals search engine
(I) Horizontal & Vertical Adjustment Screw
(I)
(J) Tilt Adjustment Screw
(K) Pan Adjustment Screw
IMPORTANT (Surface Type)
VDC-C1572FP/VDC-B1512FP
When not using the side conduit opening for wire connections,
verify that the conduit plug and set screw are tight.
(J)
SET SCREW
CONDUIT
PLUG
