INSTALLATION

Dome assembly installation
(F)
Housing
assembly
(A)
Dome
assembly
(B)
Security
Screws (4)
English
Downloaded from www.Manualslib.com
In-ceiling Type
72 mm φ
(D)
Video Out
Cable
(H)
Viewing
Window (F)
Housing
assembly
(G)
Surface Type
Mounting Screws (4)
Electrical Box
(C)
Foam Gasket
Housing
(F)
assembly
Mounting Screws (4)
Camera/VRB
assembly
3
manuals search engine
Main unit installation
•
Preparation
Make four or more holes in the ceiling or wall for the screws that
Electrical
Box
are to be used to secure the main unit. If embedding the input
(E)
Input Power power wire and video out cable, make a hole for these cables to be
Wires
passed through also.
(C)
•
Main unit installation
1
Use the accessory Hexagonal Wrench for dome cover to remove
Foam
Gasket the four screws (B) that are securing the dome assembly (A).
2
Insert the foam gasket (C) in between the housing and the
installation surface.
3
Pass the input power wire (E) and video out cable (D) through
the hole made for that purpose.
4
Align the housing assembly (F) with the screw holes that have
been prepared, and then secure it by tightening the four or
more screws (G) (4 mm diameter screws recommended).
5
Determine the lens position in accordance with the location of
the objects to be viewed, and then tighten it in that position.
(Refer to page 4 for lens adjustment details.)
6
Align the viewing window (H) with the lens position.
7
Return the dome assembly (A) to its original position and secure it.
*
(E) Input power wires: 12 V DC
NOTE: Check that the power supply voltage is 12 V DC. The unit may not
operate correctly at voltages of 14 V DC or higher.
